Standard Accessories

1.          Internal Spindle………………………1

2.          Pully for Internal Grinding…………...2

3.          Flat Belt………………………………1

4.          Diamond tool…………………………1

5.          Holder for Diamond Tool…………….1

6.          Key Folds ( 8,5,3,2 mm).......................4

Characteristic Features

1.          Both the main shafts have been specially designed, and the world-wide precision bearing is used to fit the main shafts which are made of alloy steel heat-treated for high wear resistance, precision, as well as maintaining to the lowest temperature for durability and 2.stability.

3.          The motor base and the spindle bushing are djustable.

4.          The motor is well designed with a special and nice appearance, The R.R.M. of this motor varies depending on the size of the workpiece.

5.          This grinder is capable of grinding the work piece to a minimum of 3mm in outer diameter and from 2mm up in inner diameter (bore)

6.          with the accuracy within 0.003mm and a well finished surface. (supplied with special attachments).

    The spindle bushing is made of cast iron, and supported by three surfaces.

    Therefore, it is durable and elastic.

7.          Materials such as steel, iron, copper (brass), aluminum, cast iron, plastics, porcelain, marble, regardless of being heat treated or not, can be ground on this machine which functions lie a cylindrical grinder. So it may lower the cost of the production.

    We assure you of high quality products.
